Compact and Versatile Vehicle Tracker

Efficient 4G LTE tracking with BLE 5.0, multiple I/Os, and low power consumption for diverse applications.

Advanced Tracking in a Compact Design

Seamlessly monitor assets with powerful, space-saving technology.

Real-Time and Buffered Location Updates

Provides location updates as frequent as every 3 seconds and can store up to 60,000 location points if out of network coverage.

BLE 5.0 Sensor Compatibility

Compatible with TOPFLYtech’s BLE temperature and humidity sensors, door sensors, wireless relays, and other custom sensors.

Compact and Durable Design (IP65)

Features a compact size with IP65 waterproof rating, ensuring durability in various environments.

Battery Backup

200mAh battery, suitable for backup power.

Disconnection alerts​

Alerts for device disconnected from power.

Multiple Input & Output Options

Equipped with 3 digital inputs, 2 digital outputs, and 3 configurable I/O ports for connecting various accessories.

Driving Behavior Detection


Detects reckless driving events such as harsh acceleration, turning, braking, crashes, and speeding.

Features Comparison

ZenTRACK Power+

ZenTRACK Power

ZenTRACK Warrior

ZenTRACK Knight

ZenTRACK Solar

Location Updates
Real-Time Updates Frequency
As frequent as 3 seconds
As frequent as 3 seconds
Regular updates; more frequent in SVR mode
As frequent as 3 seconds
As frequent as 3u003cbru003e seconds
Buffer Data Storage
Up to 60,000 location points
Up to 60,000 location u003cbru003epoints
Up to 60,000 locationu003cbru003e points
BLE Sensor Functionality
BLE Sensor Compatibility
General Specifications
Dimensions
132mm x 100mm x u003cbru003e34mm (5.2u0022 x 3.93u0022 x 1.34u0022)
102.5mm x 42.5mm x u003cbru003e12mm (4.04u0022 x 1.67u0022 x 0.47u0022)
82.8mm x 66.9mm x u003cbru003e35.7mm (3.26u0022 x 2.63u0022 x 1.40u0022)
91.8mm x 43.5mm x u003cbru003e29.2mm (3.61u0022 x 1.71u0022 x 1.14u0022)
85mm x 185mm x u003cbru003e31mm (3.35u0022 x 7.28u0022 x 1.22u0022)
Waterproof Rating
IP67
IP65
IP67
IP67
IP67
Operating Voltage
7V to 60V DC
7V to 60V DC
Not applicable (battery-powered)
Not applicable (battery-powered)
Not applicable (battery-powered)
Operating Temperature
-25°C to +80°C (-13°F to 176°F)
-30°C to +80°C (-22°F to 176°F)
-30°C to +80°C (-22°F to 176°F)
-20°C to +80°C (-4°F to 176°F)
-25°C to +80°C (-13°F to 176°F)
Battery Capacity
Battery Capacity
9600 mAh
200 mAh
4000 mAh (optional 8000 mAh)
6400 mAh
9600 mAh
Battery Backup Duration
Up to 20 days (5-minute reporting interval)
Not specified
Up to 3.3 years (4000 mAh) or 6.5 years (8000 mAh) with 1 report/day
Up to 247 days (10-minute reporting interval)
Lasts for months without solar charging
I/O Expandability Options
I/O Expandability Options
3 digital inputs, 3 digital outputs, 3 configurable u003cbru003einputs (digital/analog), u003cbru003e1 voltage output
3 digital inputs, 2 digital outputs, 3 configurable u003cbru003einputs (digital/analog)
Not specified
Not specified
Not specified
Driving Behavior Detection
Driving Behavior Detection
Not specified
Yes; detects harsh acceleration, turning, braking, crash, and speeding
Not specified
Not specified
Not specified
Network Operating Band
Operating Bands
u0022FDD: B1/B2/B3/u003cbru003eB4/B5/B8/B12u003cbru003e/B13/u003cbru003eB18/B19/u003cbru003eB20/B25/B28u003cbru003eTDD: B39 u003cbru003e(Cat M1 only)u003cbru003eEGPRS: 850/900/1800/u003cbru003e1900MHzu0022
u0022FDD: B1/B2/u003cbru003eB3/B4/B5/u003cbru003eB/8/B12u003cbru003e/B13/B18/B19/u003cbru003eB20/B25/B28u003cbru003eTDD: B39u003cbru003e (Cat M1 only)u003cbru003eEGPRS: 850/900/1800/u003cbru003e1900MHzu0022
u0022LTE FDD Cat M1: B1/B2/B3/u003cbru003eB4/B5/u003cbru003eB8/B12/B13/u003cbru003eB18/B19/B20/B25/B26/u003cbru003eB27/B28u003cbru003eB66/B85LTE FDD u003cbru003eCat NB2: B1/B2/B3/B4/u003cbru003eB5/B8/B12/B13/u003cbru003eB18/B19/u003cbru003eB20/B25/u003cbru003eB28/B66/B71/B85u003cbru003eGSM/EDGE: 850/u003cbru003e900/1800/1900 MHzu0022
u0022LTE FDD Cat M1: B1/B2/B3/B4/B5/u003cbru003eB8/B12/B13/u003cbru003eB18/B19/B20u003cbru003e/B25/B26/B27/u003cbru003eB28/B66/B85u003cbru003eLTE FDD Cat NB2: B1/B2/B3/B4/u003cbru003eB5/B8/B12u003cbru003e/B13/B18/B19/B20/u003cbru003eB25/B28/u003cbru003eB66/B71/B85u003cbru003eGSM/EDGE: 850/900/u003cbru003e1800/1900 MHzu0022
u0022FDD: B1/B2/B3/u003cbru003eB4/B5/B8/u003cbru003eB12/B13/u003cbru003eB19/B20/u003cbru003eB25/B28u003cbru003eTDD: B39 u003cbru003e(Cat M1 only)u003cbru003eEGPRS: u003cbru003e850/900/u003cbru003e1800/1900MHzu0022

Technical Specification

Experience innovative solutions designed to streamline your workflow and elevate performance.

Expandir todo Contraer todo

Network & Connectivity

Cellular Network

4G LTE Connectivity

Location & Navigation

Satellite Systems

GPS + Glonass + Beidou + Galileo support

Vehicle Data & Compliance

Data Reading

3 digital inputs, 2 digital outputs, and 3 configurable I/O ports

Durability & Power

Protection Rating

Battery

IP65 waterproof and rugged design

200mAh battery, suitable for backup power BLE 5.0 support

Get the Full Product Details

Frequently Asked Questions

What is the battery capacity?

The device is equipped with a 200 mAh backup battery to send disconnection alerts when power is disconnected.

Is it waterproof?

Yes, it has an IP65 rating, making it resistant to water and dust.

What networks does it support?

Supports 4G LTE CAT-M1 global bands with 2G fallback for extensive coverage.
